Body H-13 & Skirt PS-04
Body H-13 & Skirt PS-04
Massage Hot Tub for 3 persons
MODEL:
HL-2803A
The unique design with a rich experience for the spa industry makes this model a romantic 3-person spa hot tub. This model is always the best seller among many different models.
Model HL-2803A is combined with 2 loungers and 1 seat. It can provide you with full-body therapy. The CE/CB/SAA certification through the world-leading certification company, SGS Systems ensures our access to different countries.
The high-class performance of the spa is guaranteed by using American Aristech acrylics and Balboa controller and other superior materials.
Specifications
- External dimensions: 2000 x 1600 x 920mm.
- Seats: 3.
- Water capacity: 950Lt.
- Dry weight: 280kgs.
- American Aristech acrylic for the shell.
- 48 x Stainless steel water jets.
- 8 x Air nozzles.
- 1 x Circulation pump 0.5hp.
- 2 x Massage water pump 2hp.
- 1 x Air blower 400W.
- 1 x Heater 3kW.
- 1 x Ozone disinfection system 50mg/h.
- 1 x Ozone injector and mixer.
- 1 x Large bottom LED light.
- 1 x Multifunctional control system.
- 1 x High-effective filter cartridge (Quiet and energy-saving filtration system).
- 1 x Skirt with maintenance-free synthetic cabinet.
- 1 x Spa bottom drain.
- 1 x Side drain valve.
- 2 x Headrest.
- 1 x Spa protecting bag.
- 1 x Cover.
- 1 x Mushroom fountain.
- Automatic anti-freezing system.
- Time-programmed circulation and disinfection system.
- Protection of overvoltage and under voltage.
- FRP bottom base.
- Insulation for spa body and cabinet.
- Automatic water refilling system.
- Upgraded Balboa system that allows control and use of spa’s functions via WiFi anywhere anytime (WiFi receiver is needed).
- Self-air-releasing feature that does not allow air to remain inside the spa’s piping system, causing malfunction at the circulation pump.
18 x Perimeter led lighting of 7 different colours, located around spa pillows and spa waterfalls.
POWER SUPPLY
- Electricity supply: 220V/50-60Hz or 380V/50-60Hz.
- Maximum current: 29A.
Colour Chart
COLOURS FOR SHELL (ARISTECH ACRYLIC)
ZOOM IN
H-01(6696): White Pearlescent
H-01(6696): White Pearlescent
H-02(6615): Summer Sapphire
H-02(6615): Summer Sapphire
H-03(6878): Midnight Opal
H-03(6878): Midnight Opal
H-04(6863): Azure Metalescent
H-04(6863): Azure Metalescent
H-05(9814): Gypsum
H-05(9814): Gypsum
H-06(6427): Silver White Marble
H-06(6427): Silver White Marble
H-07(6811): Oceanwave
H-07(6811): Oceanwave
H-08(9583): Sahara
H-08(9583): Sahara
H-09(6459): White
H-09(6459): White
H-10(6240): Mediterranean Sunset
H-10(6240): Mediterranean Sunset
H-12(6970): Oyster Opal
H-12(6970): Oyster Opal
H-13(6256): Mayan Copper
H-13(6256): Mayan Copper
H-14(6301): Odyssey
H-14(6301): Odyssey
COLOURS FOR SKIRT
ZOOM IN
PS-01 Coffee
PS-02 Grey
PS-03 Natural
PS-04 Black
PS-05 Red
COLOURS FOR COVER
ZOOM IN
C-01: Solid Black
C-02: Solid Grey
C-03: Red Brown
C-04: Light Brown
C-05: Stripe Grey
C-06: Dark Brown
C-07: Stripe Black
C-08: Coffee
LIGHTS COLOUR
ZOOM IN
Blue
Cyan
Green
Purple
Red
Additional equipment
Ordinary spa step
MODEL: Spa step
Drink Tray
MODEL: Drink tray
